n8n database connection timed out – PostgreSQL pool exhausted fix

Who this is for: SREs, DevOps engineers, and platform architects running n8n in production‑grade queue mode (Kubernetes, Docker‑Compose, or managed container services). We cover this in detail in the n8n Queue Mode Errors Guide.

---

Quick Diagnosis (Featured‑Snippet Ready)

Symptom: In queue mode n8n logs Error: Failed to connect to database and stops processing jobs.

Root cause: The workflow‑executor’s MySQL/PostgreSQL client cannot establish or maintain a DB connection (wrong credentials, TLS mismatch, connection‑pool exhaustion, or network/firewall block).

One‑line fix: Verify DB credentials & TLS settings, then raise N8N_QUEUE_MODE_DB_MAX_CONNECTIONS (default 5) to match your workload, and restart n8n.

---

1. How n8n Uses the Database in Queue Mode

If you encounter any n8n queue mode redis unavailable resolve them before continuing with the setup.

Component → Role

Component	Role in Queue Mode
Workflow Executor	Pulls pending jobs from execution_entity, updates status, writes results
Job Scheduler (BullMQ)	Stores job metadata in the same DB (when queueMode=database)
Health‑Check Endpoint	Periodically pings DB to report “queue‑mode‑healthy”

Component → Typical Failure Point

Component	Typical Failure Point
Workflow Executor	Connection timeout, authentication error
Job Scheduler (BullMQ)	Pool exhaustion, dead‑lock
Health‑Check Endpoint	Mis‑configured health‑check interval

EEFA note: In production, each executor pod or Docker container opens its own pool. Over‑provisioning without increasing N8N_QUEUE_MODE_DB_MAX_CONNECTIONS quickly saturates the DB, causing intermittent failures.

---

2. Step‑by‑Step Troubleshooting Checklist

Micro‑summary: Follow these actions in order to isolate network, credentials, TLS, and pool‑size problems.

Step	Action	Command / Config
1	Confirm DB is reachable from the n8n host	nc -zvw3 <DB_HOST> <DB_PORT>
2	Validate credentials (user, password, database)	mysql -u $USER -p$PASS -h $HOST $DB or psql "host=$HOST dbname=$DB user=$USER password=$PASS"
3	Check TLS/SSL settings – match N8N_QUEUE_MODE_DB_SSL flag	openssl s_client -connect $HOST:$PORT -servername $HOST
4	Inspect connection‑pool size – default 5 may be too low	echo $N8N_QUEUE_MODE_DB_MAX_CONNECTIONS
5	Review DB server logs for “too many connections” or auth failures	tail -f /var/log/mysql/error.log
6	Increase pool size (recommended 20‑30 for medium load)	export N8N_QUEUE_MODE_DB_MAX_CONNECTIONS=30
7	Restart n8n to apply env changes	docker restart n8n or kubectl rollout restart deployment/n8n
8	Validate queue health via API	curl http://localhost:5678/healthz → look for "queueMode":"healthy"
9	Monitor for 15 min (Prometheus/Grafana or docker logs -f n8n)	–
10	Persist env changes in your orchestration (docker‑compose, k8s ConfigMap)	–

EEFA warning: Setting the pool too high can overwhelm the DB, especially on managed services with connection caps (e.g., AWS RDS default 150). Stay within 70 % of the DB’s max_connections. If you encounter any n8n queue mode sqlite locking issue resolve them before continuing with the setup.

---

3. Configuring Database Connection for Queue Mode

3.1 Environment Variables Overview

Variable	Example	Description
N8N_QUEUE_MODE	database	Enables DB‑backed queue mode
DB_TYPE	postgresdb	postgresdb or mysqldb
DB_POSTGRESDB_HOST	db.mycompany.internal	Hostname / IP
DB_POSTGRESDB_PORT	5432	Port
DB_POSTGRESDB_DATABASE	n8n	Database name
DB_POSTGRESDB_USER	n8n_user	DB user
DB_POSTGRESDB_PASSWORD	••••••	Secret (Docker secret / k8s Secret)
DB_POSTGRESDB_SSL	true	Force TLS (recommended)
N8N_QUEUE_MODE_DB_MAX_CONNECTIONS	30	Max connections per n8n instance
N8N_QUEUE_MODE_DB_CONNECTION_TIMEOUT	5000	ms before aborting connection attempt

3.2 Docker‑Compose – Service Definition

services:
  n8n:
    image: n8nio/n8n:latest
    ports:
      - "5678:5678"
    depends_on:
      - postgres

Docker‑Compose – Environment Block

environment:
  - N8N_QUEUE_MODE=database
  - DB_TYPE=postgresdb
  - DB_POSTGRESDB_HOST=postgres.internal
  - DB_POSTGRESDB_PORT=5432
  - DB_POSTGRESDB_DATABASE=n8n
  - DB_POSTGRESDB_USER=n8n_user
  - DB_POSTGRESDB_PASSWORD=${POSTGRES_PASSWORD}
  - DB_POSTGRESDB_SSL=true
  - N8N_QUEUE_MODE_DB_MAX_CONNECTIONS=30
  - N8N_QUEUE_MODE_DB_CONNECTION_TIMEOUT=8000

EEFA tip: Store POSTGRES_PASSWORD in a Docker secret or Kubernetes Secret; never hard‑code it.

3.3 Kubernetes – Deployment Metadata

apiVersion: apps/v1
kind: Deployment
metadata:
  name: n8n
spec:
  replicas: 3
  selector:
    matchLabels:
      app: n8n

Kubernetes – Container Spec

template:
  metadata:
    labels:
      app: n8n
  spec:
    containers:
      - name: n8n
        image: n8nio/n8n:latest
        envFrom:
          - secretRef:
              name: n8n-db-creds
        env:
          - name: N8N_QUEUE_MODE
            value: "database"
          - name: DB_TYPE
            value: "postgresdb"
          - name: N8N_QUEUE_MODE_DB_MAX_CONNECTIONS
            value: "25"
          - name: N8N_QUEUE_MODE_DB_CONNECTION_TIMEOUT
            value: "7000"
        ports:
          - containerPort: 5678

EEFA note: With three replicas, each pod requests 25 connections → 75 total. Ensure PostgreSQL max_connections is > 90 to leave headroom for admin tools.

---

4. Deep‑Dive into Common Failure Scenarios

4.1 Invalid TLS Certificate

Symptom: error: self signed certificate in logs.

Root cause: DB server presents a cert not trusted by the n8n container.

Fix:

1. Temporary test – set DB_POSTGRESDB_SSL_REJECT_UNAUTHORIZED=false.
2. Production – import the CA cert into the container:

   COPY ca.crt /usr/local/share/ca-certificates/
   RUN update-ca-certificates

3. Or switch to SSL_MODE=verify-full with proper hostname verification.

4.2 “Too many connections” Error

Log excerpt: Error: connect ECONNREFUSED - connection pool exhausted.

Why it happens: Each workflow execution opens a new DB client; the pool limit is hit before the DB can recycle idle connections.

Resolution:

• Increase N8N_QUEUE_MODE_DB_MAX_CONNECTIONS.
• Reduce concurrent executions via EXECUTIONS_PROCESS=1 if you cannot raise DB limits.
• Enable an idle timeout (default 30 s) by setting N8N_QUEUE_MODE_DB_IDLE_TIMEOUT=20000.

4.3 Network Policy Blocking Port

Symptom: connect ECONNREFUSED <IP>:5432 after initial successful connections.

Cause: Kubernetes NetworkPolicy or cloud security group restricts concurrent connections per pod.

Action:

1. Verify NetworkPolicy ingress rules allow traffic from the n8n namespace to the DB service.
2. In AWS, adjust the **Security Group** outbound rule to allow tcp:5432 for the pod’s ENI.

---

5. Monitoring & Alerting for Queue‑Mode DB Health

5.1 Prometheus – Scrape Config (n8n v0.215+)

scrape_configs:
  - job_name: 'n8n'
    static_configs:
      - targets: ['n8n:5678']
    metrics_path: '/metrics'

5.2 Prometheus – Relevant Metrics

Metric	Meaning	Alert Threshold
n8n_queue_db_connections	Current active DB connections	> 0.8 × max_connections
n8n_queue_db_errors_total	Cumulative connection errors	> 5 per minute

EEFA recommendation: Pair alerts with an automatic pod restart (kubectl rollout restart) to recover from transient blips, but always investigate the root cause first.

5.3 Grafana Loki – Log‑Based Alert

{app="n8n"} |~ "Failed to connect to database|ECONNREFUSED|TLS handshake"
|= "queue mode"
| count_over_time(5m) > 3

---

TL;DR (Featured Snippet)

Problem: n8n in queue mode stops processing with “Failed to connect to database”.
Fix: Verify DB host/port, user, password, and TLS; then raise N8N_QUEUE_MODE_DB_MAX_CONNECTIONS (e.g., to 30) and restart n8n. Ensure the DB’s max_connections exceeds the total needed by all n8n instances.

---

All commands assume a Unix‑like shell. Adjust paths and secret handling for Windows containers as needed.
